The right repairs

Choosing the right model for the application and performing routine maintenance are keys to reaching the potential of moving-floor trailers.

Photos courtesy of Hallco Industries

Within the waste industry, moving floors play a critical role in unloading bulk materials or pallets from trailers. The benefit of a moving floor comes from its ability to move large amounts of material without the need for additional tools or extensive operator assistance. Trailers equipped with a moving floor unload materials using a series of slats or planks that are powered by hydraulic cylinders. These systems come in variations with slats of different thicknesses, each suited to applications involving specific types of material. They can move municipal solid waste (MSW), single-stream recyclables, cardboard, wood chips, mulch and compost, among other materials.

To ensure the optimal use of a moving floor, waste haulers must be aware of maintenance measures and the wear-and-tear that some materials can have on the system.

Moving floor benefits

Richard Moffitt, vice president of sales and marketing for Hallco Industries, a Tillamook, Oregon-based company that manufactures Live Floors, its brand of moving floors, says three primary types of trailers are used for transporting waste and recycling: belt trailers, tipper trailers and moving-floor trailers.

Belt trailers contain a belt in the center that pulls materials out the back. A tipper can be tilted up by a hydraulic arm to dump materials.

A moving-floor trailer has greater capacity and can accommodate a broader range of materials compared with a belt trailer, Moffitt says. For tippers, it often takes a considerable amount of time to secure the trailer, and safety issues can be a concern.

Mike Robinson, sales director at Madras, Oregon-based moving-floor producer Keith Manufacturing, says many landfills do not have the tipper device needed to lift trailers. A tipper device and the trailer itself also could fall over if the landfill ground is unstable. Moving floors do not experience this risk because the trailer stays horizontal on the ground.

“I think it’s a more stable system to use with limited chances of actually tipping over,” Moffitt says. “[There is] greater capacity, so you can haul 20 to 27 percent more material than you can in a belt trailer, and then … [you have] the ability to haul multiple bulk materials, so one day you can haul trash, the next day you could haul auto fluff, the day after that you’re hauling recyclables. The trailer is just that versatile.”

Robinson says trailers equipped with Keith’s brand of moving floor, the Walking Floor system, are not hindered by delays from other material handling equipment and can unload in different locations.

Tarps can be added to a moving-floor system for cleaning purposes, as found in Keith’s CleenSweep System. The CleenSweep system can be powered hydraulically or electronically. The hydraulic version often is built into trailers that have a Walking Floor installed. Robinson says it is the more powerful of the two versions and is low maintenance, though it is more difficult to install if not purchased at the time the trailer is being manufactured.

He says the electric version is popular in aftermarket sales because of the ease of installation and adds that while the CleenSweep is not necessary for all waste handling applications because a Walking Floor can clean most MSW products without a tarp, it is helpful when unloading other materials, such as C&D debris, food waste and mulch and compost byproducts.

Moving floor selection

Moffitt says choosing a moving-floor system requires a waste hauler to consider the type of materials it will most commonly handle and how they will be loaded. This is often done with a compactor or by top loading using a wheel loader or material handler, for instance. A thick floor with high-impact resistance works well when hauling C&D waste, whereas a flatter floor works well for hauling lighter recyclables.

In most moving-floor systems, every third slat is connected to a cross drive, with eight to nine slots per cross drive, Moffitt says. Cross drivers are connected to the hydraulic drivers (cylinders) underneath the hydraulic module. To unload, the system pushes all slats toward the trailer’s rear at once. It also can reverse the direction to load material into the trailer.

The slats must retract in a pattern to break stack friction. To move a pile of materials, two-thirds of the floor must stay still while one-third retracts. Once all three sections retract, the floor moves again, bringing the pile along.

Moffitt says most moving floor slats are made of aluminum because the metal has a greater coefficient for friction, meaning it pulls the material out of the trailer more efficiently.

Maintenance considerations

In terms of preventive maintenance for moving floors, haulers should tighten all bolts, including deck bolts and drive bolts, and check lug nuts.

Moffitt says problems pertaining to hydraulic oil can pose detriments to these systems. Running a high-pressure filter and a return filter into the hydraulic tank helps remove small particles and contaminants that pass through and cut hydraulic seals. It is important, Moffitt says, to run enough clean oil through the system. He recommends 30 gallons per minute at 3,000 psi, typical parameters for moving floors. Running more than this will shake the system and wear parts prematurely.

Operators also should keep an eye on the rear slats because the back half of the trailer sees 100 percent of the load going across it, while the front half does not see as much of the load, Moffitt says. Checking for wear on the slat legs is necessary, as they hold the slats down. To address this wear, haulers can flip the slats front to back, potentially doubling their lives.

Monthly maintenance recommendations for Keith’s Running Floor II, the drive system for its Walking Floor, include checking for hydraulic leaks, checking operating temperature, torquing cylinder barrel clamp bolts and pressure washing the drive unit, subdeck and slats. For six-month service, Keith recommends changing the oil filters, cycling the system briefly in both directions to observe proper operation and inspecting components for wear.

The lifespan of a moving floor primarily depends on the number of loads per day and the type of material being unloaded. An abrasive product, such as single-stream recyclables with glass mixed in, can erode a floor faster than cardboard, Moffitt says. Given the right treatment, a moving floor trailer that is hauling municipal waste could last seven to 10 years. A trailer that hauls mostly cardboard or other light materials could last longer than 10 years.

Sand, gravel, glass and auto fluff are most likely to wear down not only the moving floor but the whole trailer. Moving floors with thicker designs are better for handling these materials, and an overlapping floor will help protect floor slat seals.

Moffitt says selecting and using moving floors involves balancing cost and weight with longevity.

“You can buy a thinner floor that gives you less weight in the trailer, so you can haul more payload, but you’re going to have to replace floor slats sooner because you’re sacrificing early to get payback,” Moffitt says.

He says it is key to build a relationship with a nearby dealer to quickly obtain spare parts for moving floor systems. Moffitt says this could be more beneficial than end users trying to maintain their own supply of inventory because haulers likely will not need spare parts for seven to 10 years.

Robinson says, though, that it is best for moving floor owners to have at least a check valve, switching valve and hydraulic cylinder on hand in case the system malfunctions.

The author was a prior intern for Recycling Today Media Group.
